Victron BlueSolar PWM Charge Controller LCD&USB 12/24-30 30A
Modelo: BlueSolar LCD&USB 12/24-30- Sku: VICTREG054
- Vendor: Victron
Specifications
Product Description
The Victron BlueSolar LCD&USB 12/24-30 30A is the highest current model in the LCD&USB family for 12 V and 24 V systems. It maintains the common positive PWM architecture with very low self-consumption, while incorporating an LCD screen for local configuration, integrated day/night timer, and dual 5 V USB ports (2 A total) for small auxiliary loads. Its three-stage charging algorithm protects the battery, and the output with low voltage disconnect prevents deep discharges, ensuring reliability and long service life in installations with larger PV surface area or higher continuous consumption.
Main Features
- 30 A charging current with automatic 12/24 V detection.
- LCD screen: voltage settings, LVD and timer; instant status reading.
- Optimized multi-stage charging for lead-acid: absorption ≈14.4 V/28.8 V and float ≈13.7 V/27.4 V.
- Dual USB 5 V/2 A total for mobile devices, sensors, or 4G router.
- Protections: PV/battery reverse polarity, overload, output short circuit, and overtemperature.
- Max PV (Voc) 28 V (12 V) / 55 V (24 V) and self-consumption <10 mA.
Advantages or Benefits
- Greater capacity than 5/10/20 A models without losing simplicity or cost-effectiveness.
- Protects the battery and reduces maintenance through precise charge management and LVD.
- Automates lighting with the built-in timer, avoiding additional devices.
- Very quick installation: common positive, terminals up to 6 mm², and compact format.
- Maximum energy utilization thanks to its ultra-low internal consumption.
Purpose or Applications
Recommended for autonomous public and residential lighting, signage, cabins and properties with higher consumption, camper vans and marine use with multiple lighting points, remote stations with additional equipment, and small self-consumption systems at 12/24 V.
Technical Specifications
| Battery voltage | 12/24 V (automatic detection) |
| Charging current | 30 A |
| USB | 2×5 V; 2 A total |
| Charging algorithm | Absorption ≈14.4 V / 28.8 V · Float ≈13.7 V / 27.4 V |
| LVD / Reconnection | ≈11.2 V / 22.4 V · ≈12.6 V / 25.2 V (manual) |
| Max PV (Voc) | 28 V (12 V) / 55 V (24 V) |
| Self-consumption | < 10 mA |
| Load output | LVD + day/night control with timer |
| Grounding | Common positive |
| IP rating | IP20 |
| Terminals | Up to 6 mm² (AWG10) |
| Dimensions / Weight | 96 × 169 × 36 mm · ≈0.15 kg |
Compatibilities
Compatible with 36-cell panels (12 V) and 72-cell or 2×36-cell panels (24 V). Recommended batteries: lead-acid AGM/GEL/flooded; use with LiFePO₄ only with BMS and proper control. Accessories: DC fuses/fuse holders, disconnectors, surge protectors, and wiring suitable for the current.
Victron BlueSolar LCD&USB 12/24-30 30A is the high-current PWM option for 12/24 V that integrates control, protection, and practical utilities in a compact and reliable device.
