What are Electrical Panels and Boxes?

The Electrical Panels and Boxes collection includes enclosures, chests, and mini-panels for integrating protections and connections of PV systems. Available in different sizes, materials, and protection ratings.

Advantages and limitations

• Safety due to insulation and appropriate IP/IK rating.
• Order and simplified maintenance with DIN rail and reserves.
• Limitation: useful capacity and space; calculate required DIN modules.

Applications

• DC section of strings and gPV protections.
• AC section of inverter/grid with protections.

How to choose

• Define location (indoor/outdoor) and required IP/IK.
• Size DIN modules and reserve for future expansions.
• Plan for cable entry, cable glands, and terminal block arrangement.

Specifications (indicative)

Related

Combine with DC Protections, AC Protections, Connectors, and Cables. Full catalog in Electrical Material.
