Protection Panel Kits (AC and DC)

Los Kits de Cuadros de Protecciones (CA y CC) agrupan magnetotérmicos, diferenciales, fusibles y SPD coordinados para cumplir normativa y proteger tu sistema FV.

Úsalos para garantizar seguridad, selectividad y facilidad de instalación en autoconsumo, aislada o bombeo.

What is an AC and DC Protection Board Kit?

A Protection Board Kit is the set of enclosures and devices for disconnection, overcurrent, residual current, and surge protection for the DC section (PV string) and AC section (inverter/grid), ready to integrate into your installation.

Advantages and limitations

Regulatory compliance and coordination between protections.
Faster assembly and lower risk of errors.
Limitation: preset values (In, Icu, Ucpv); check compatibility with your system.

Applications

Self-consumption without Battery and with Battery.
Off-grid 12/24/48V and Solar Pumping.

How to choose

Check the maximum DC voltage and current per string.
Select suitable SPDs (PV DC and AC at the main connection).
Confirm the rating of disconnectors and fuses with respect to the inverter.

Typical specifications

Sections	DC (strings) and AC (inverter/grid)
Protections	Miniature circuit breakers, fuses, residual current devices, SPDs
IP rating	According to location (indoor/outdoor)
Connection	Identified terminals and diagrams
Compatibility	With self-consumption, off-grid, and pumping kits
