Deye Sun 8kW SG01LP1-EU Single-Phase Hybrid Inverter

Modelo: SUN-8K SG01LP1-EU

Sku: DEYEINV003
Vendor: Deye

€2.350,53 EUR

€1.880,42 EUR

Tax included.

Shipping calculated at checkout.

In stock!

Spend €150,00 to FREE SHIPPING

Deye Sun 8kW SG01LP1-EU Single-phase Hybrid Inverter offers advanced management, EPS, and communications. With 190 A for battery, 2 MPPT, and IP65 protection, it allows AC retrofit, savings with TOU, and expansion up to 16 units.

Product variants

Quantity

I agree with the Terms and Conditions.

Purchase with Secure Payment

Specifications

Product Description

The Deye Sun 8kW SG01LP1-EU Single-Phase Hybrid Inverter is a 48 V hybrid that combines power, flexibility, and safety for residential and light commercial self-consumption projects. It integrates dual MPPT to extract maximum performance from your panels, EPS mode for backup, time-of-use (TOU) scheduling for up to six periods, and communications for remote monitoring. With IP65 protection, a touch LCD screen, and the option to operate in parallel with up to 16 units, it is ready to grow with your photovoltaic installation, both in new systems and in retrofit with AC coupling.

Main Features

Nominal AC power: 8 kW single-phase (230 V, 50/60 Hz) with a maximum power of 8.8 kW.
Solar architecture: 2 independent MPPTs (1 string per MPPT), MPPT range 150–425 Vdc, and max PV voltage 500 Vdc.
48 V battery management: window 40–60 V and max. 190 A charge/discharge current (lithium via CAN/RS485 or AGM/GEL lead-acid).
EPS backup: peak 2× nominal power for 10 s and fast switching for critical loads.
Parallel and retrofit: up to 16 units in parallel (on/off-grid) and AC coupling with existing PV inverters.
Reference efficiencies: 97.6% max., 97.0% European, and MPPT tracking at 99.9%.

Advantages or Benefits

Electricity savings: prioritizes solar consumption and allows programming of 6 TOU periods to charge during off-peak and discharge during peak hours.
Service continuity: EPS output maintains lighting, ICT, or refrigeration during grid outages.
Robust installation: IP65 rating, intelligent cooling, and integrated DC isolator for greater safety.
True scalability: possibility of parallel operation, zero-export with meter/CT, and expansion without redoing the installation.
Total control: portal/app with telemetry, events, and remote updates; optional Wi-Fi/BT/4G/LAN dongles.

Purpose or Applications

Ideal for homes with medium/high consumption, single-phase businesses, workshops, and rural accommodations seeking self-consumption with storage, backup during outages, and tariff optimization. Perfect for new plants and for upgrading existing systems via AC coupling (retrofit).

Technical Specifications

Power	8 kW nominal AC · 8.8 kW max. · EPS peak 2× (10 s)
Voltage / Frequency	230 Vac single-phase (0.85–1.10 Un) · 50/60 Hz
PV input	10.4 kWp max. · 2 MPPT (1+1) · 150–425 Vdc · Voc max. 500 Vdc
PV current	26 A per MPPT (admissible Isc 44 A per MPPT)
Battery	48 V (40–60 Vdc) · up to 190 A charge/discharge · thermal probe
Efficiency	97.6% max. · 97.0% European · MPPT 99.9%
AC passthrough	Up to 50 A continuous (grid → loads)
Power factor	Adjustable 0.8 inductive ↔ 0.8 capacitive · THDi < 3%
Protections	IP65 · Anti-islanding · RCD/RCMU · SPD Type II DC / Type III AC · DC isolator
Dimensions / Weight	420 × 670 × 233 mm · ≈ 32 kg
Communication	RS485 / CAN / RS232 · Wi-Fi/BT/4G/LAN/GPRS with dongle
Environment	−40…+60 °C (derating > 45 °C) · 0–100% RH (non-condensing)

Compatibilities

This product is compatible with 48 V battery banks with BMS via CAN/RS485 (LiFePO₄/NMC) and with AGM/GEL, single-phase meter or CT clamps for zero-export, and communication dongles (Wi-Fi/BT/4G/LAN). No internal links to specific models have been provided.

Deye Sun 8kW SG01LP1-EU Single-Phase Hybrid Inverter is a professional solution for demanding renewable energy projects. It increases autonomy, optimizes space, and improves the efficiency of your installation.
