Solax X3-HAC-22P 22kW Single-Phase Electric Vehicle Charger with CT

Modelo: X3-HAC-22P

Sku: SOLXCAR006
Vendor: Solax

€1.109,87 EUR

€887,89 EUR

Tax included.

Shipping calculated at checkout.

In stock!

Spend €150,00 to FREE SHIPPING

The Solax X3-HAC-22P 22kW EV Charger with hose and CT offers three-phase charging 400 V 32 A, IP65 and RCD 30 mA AC + 6 mA DC. WiFi/Ethernet, RFID, PEN protection, and dynamic balancing to take advantage of solar surplus.

Product variants

Quantity

I agree with the Terms and Conditions.

Purchase with Secure Payment

Specifications

Product Description

The Solax X3-HAC-22P 22kW Electric Vehicle Charger belongs to the Smart EV Charger G2 range and is designed for fast charging in three-phase installations. It delivers up to 22 kW (400 V, 32 A per phase) and communicates with the SolaX ecosystem to prioritize photovoltaic surplus and adjust power in real time via CT clamp(s). It features WiFi/Ethernet connectivity, RFID authentication, control via APP and web, and an IP65 enclosure that allows for indoor or outdoor use. Its electronics integrate RCD 30 mA AC + 6 mA DC, PEN protection, relay welding detection, and thermal monitoring, ensuring safe charging in compliance with regulations.

Main Features

22 kW three-phase: 230/400 V, 6–32 A per phase (single-phase mode compatible).
SolaX solar integration: charges with surplus and allows scheduling from the APP.
Connectivity: WiFi/Ethernet (optional 4G), RS485×2; control via APP and web portal.
Access management: RFID, Plug & Charge, and user profiles.
Advanced safety: RCD 30 mA AC + 6 mA DC, over/undervoltage, overcurrent, overtemperature, short circuit, and earth protection.
Dynamic load balancing: CT clamp/meter to limit power and prevent ICP tripping.

Advantages or Benefits

Faster charging: 22 kW on 3 phases reduces charging times compared to 7.4 kW or 11 kW.
Savings and sustainability: utilizes available solar energy and schedules charging during off-peak hours.
Simplified installation: IP65, 6.5 m Type 2 cable, and integrated PEN protection.
Professional management: history logs, multi-user control via RFID, and OCPP 1.6j (optional) for platforms.
Reliability: robust design (IK10 enclosure) and passive, silent cooling.

Purpose or Applications

Ideal for three-phase homes, private parking, businesses, and SMEs requiring fast, safe, and connected charging. Thanks to dynamic CT control, it operates alongside other loads without exceeding the contracted power.

Technical Specifications

Model	X3-HAC-22P (Smart EV Charger G2)
AC Output	22 kW · 230/400 V · 6–32 A (three-phase; single-phase mode compatible)
Charging method	Type P (cable with Type 2 connector)
Cable length	≈6.5 m
Connectivity	WiFi / Ethernet / (optional 4G) / RS485×2
Protocols	OCPP 1.6j (optional), Modbus TCP/RTU, Cloud API; IEC 61851-1
Authentication	RFID, Plug & Charge, and APP
Load balancing	Dynamic control with CT clamp(s) / MID meter (optional)
Protections	RCD 30 mA AC + 6 mA DC, over/undervoltage, overcurrent, overtemperature, short circuit, earth, relay welding detection
Degree / impact	IP65 / IK10 enclosure (IK08 display)
Dimensions / weight	≈390×206×139 mm · ≈6.5 kg (Type P)
Environmental range	−30…50 °C; 5–95 % RH (non-condensing); altitude ≤ 2000 m
Mounting	Wall or pedestal

Compatibilities

Direct integration with SolaX inverters and batteries to prioritize surplus and limit power via CT. Compatible with most electric vehicles with Type 2 connector.

The Solax X3-HAC-22P 22kW Electric Vehicle Charger combines three-phase power, advanced safety, and solar integration for professional, efficient, and easy-to-manage charging.
